Yas Compression Fitting Poj Niam Threaded Tee
PP Compression Fittings-Txo txuas
SMART PP compression fittings kab tau tsim rau cov khoom ntawm dej ntawm lub siab siab, rau kev xa dej, rau cov dej xa tawm thiab cov ntawv thov siv hauv thermo-hydraulic sector. Cov kab khoom no tau ua raws cov txheej txheem thoob ntiaj teb loj tshaj plaws ntawm cov khoom siv kho tshuab thiab alimentary sib xyaw.
Cov Lus Qhia Ntxiv Khoom
PPR Haum / Yeeb Nkab Choj
1. OEM Muaj
2. PP Khoom Siv: R200P
3. ISO15874 DIN8077 / 8078
4. ISO9001 14001 AENOR CE
PPR Haum / Yeeb Nkab Choj
Nta:
Cov khoom siv: PP PP zoo (HYOSUNG R200P, Kauslim Teb)
Siab Ntsuam Xyuas: 2.5MPa
Txuj: ISO 15874: 2003, DIN8077-8078
Daim ntawv thov kub: -40 - +95 ° C
Ntawv pov thawj: ISO9001, ISO14001, AENOR
PP Compression Fittings-Txo txuas
SMART PP compression fittings kab tau tsim rau cov khoom ntawm dej ntawm lub siab siab, rau kev xa dej, rau cov dej xa tawm thiab cov ntawv thov siv hauv thermo-hydraulic sector. Cov kab khoom no tau ua raws cov txheej txheem thoob ntiaj teb loj tshaj plaws ntawm cov khoom siv kho tshuab thiab alimentary sib xyaw.
Cov ntaub ntawv txheej txheem.
Cov Khoom Siv
| Feem | Cov Khoom Siv |
| Lub cev (A) | Heterophasic block polypropylene co-polymer (PP-B) ntawm tshwj xeeb cov yam ntxwv tsis txawm hais tias thaum siab kub. |
| Thaiv cov hav txwv yeem (D) | Polypropylene |
| Txiv ntoo (B) | Polypropylene nrog cov xim tswv ntawm kev kub siab rau UV UV andsolidity kom sov (S qib raws li tus qauv DIN54004) |
| Clinching nplhaib (C) | Polyacetal resin (POM) nrog lub cuab yeej siab Thiab hardness |
| O Nplhaib gasket (E) | Cov roj ntsha tshwj xeeb elastomeric acrylonitrile roj hmab (EPDM) rau kev siv alimentary |
| Reinforcing nplhaib | AISI 430 (UNI X8Cr17, W, nr 14828) Stainless hlau rau poj niam xov los ntawm 1" txog 4" |
Ua Haujlwm Pressures
SMART PP compression fittings pub rau qhov siab tshaj plaws ua haujlwm siab (PN ~ PFA *) ntawm 16 bar (UNI 9562) rau cov diameters los ntawm 16mm mus rau 63mm thiab PN10 bar rau diameters los ntawm 75mm txog 110mm, ntawm qhov kub ntawm 20 ° C.Maximum tso cai ua haujlwm ua haujlwm. muaj feem xyuam nrog lub sijhawm ua haujlwm siab thiab kub:
| Dn | PFA * | PMA * | PEA * |
| 16-63 | 16 | 20 | 24 |
| 75-110 | 10 | 12.5 | 15 |
| Kub (° C) | Da-10a25 | Da+26a+35 | Da+36a+45 |
| 16-63 | 16 | 20 | 24 |
| 75-110 | 10 | 12.5 | 15 |
Qauv Qauv
Qhov loj me: UNI 9561Working
Siab: UNI 9562, DIN 8076-3, ISO 14236, BRL-K03.
Polyethylene (PE) kav dej: UNI 7990, DIN 8074, UNI EN 12201
Xov: UNI ISO7 / 1, UNI EN 10026-1, ANSI ASME B1-20.1
Flanges: DIN 2501-1, UNI EN 1452-3.IS 7005-2
